The KROHNE OPTIFLUX 2050 is a robust electromagnetic flowmeter for large sewage and wastewater lines up to DN 1200. With hard rubber liner and virtual reference technology, it handles solids-laden fluids without grounding rings. The IFC 050 converter provides reliable 4-20 mA and pulse outputs with empty pipe detection. Offering ±0.3% accuracy and IP68 submersion rating, it is perfect for sewage treatment plants, combined sewer overflow, and industrial discharge where durability and low maintenance are essential.
| Parameter | Specification |
|---|---|
| Measuring Principle | Electromagnetic |
| Size Range | DN 25 to DN 1200 |
| Accuracy | ±0.3% o.r. ± 2 mm/s |
| Conductivity | ≥ 20 µS/cm |
| Process Temperature | -5°C to +90°C |
| Pressure Rating | PN 10 to PN 16 |
| Liner | Hard rubber |
| Outputs | 4-20 mA, Pulse, Status |
| Protection | IP68 |
| Certifications | ATEX Zone 2 (optional) |
DN 1200 (48 inches).
Yes, full-bore design with hard rubber liner.
Yes, IP68 rated for continuous submersion.
Yes, virtual reference technology.
Yes, up to 50 m cable length.
For more information about the OPTIFLUX 2050 large sewage version, pricing, or to request a demo, contact our team:
