The AUMA SA 07.5‑F10 is a compact, high-performance multi-turn electric actuator designed for precise valve automation in demanding industrial environments. Delivering 30–60 Nm torque with a standard F10 flange, it features non-intrusive electronic setting via MWG magnetic limit and torque sensing, eliminating the need to open the housing. The integrated AUMATIC AC 01.2 control unit supports MODBUS RTU, Profibus DP, and HART, with optional Bluetooth commissioning. With IP68 enclosure and Ex d IIC T4 explosion-proof certification, it ensures reliable operation in oil & gas, water treatment, and power plants. Ideal for gate, globe, and sluice valves requiring accurate positioning and diagnostic feedback.
| Parameter | Specification |
|---|---|
| Model | SA 07.5‑F10 |
| Torque Range | 30–60 Nm |
| Output Speed | 4–90 rpm @ 50 Hz |
| Mounting Flange | F10 (ISO 5210) |
| Motor | 3-phase AC, 380–480 V |
| Limit Switches | 2 x Open/Close (250 V, 5 A) |
| Position Feedback | 4–20 mA (optional RWG) |
| Enclosure | IP68, NEMA 6 |
| Explosion Protection | Ex d IIC T4 Gb |
| Ambient Temperature | -30°C to +70°C |
| Weight | 28 kg |
Electronically via AUMATIC, no mechanical adjustment needed.
Yes, via optional Bluetooth with AUMA CDT software.
Yes, Ex d IIC T4 certified for Zone 1.
Yes, with optional RWG electronic position transmitter.
S2-15 min / S4-25% (1,200 c/h) per IEC 60034.
For more information about the AUMA SA 07.5‑F10, pricing, or to request a demo, contact our team:
